Injection Waterproof Trolley Carry Case (493621)

Model: 493621

Inner Dimensions (L×W×H): 493×368×221mm (19.41"×14.49"×8.70")

Outer Dimensions (L×W×H): 557×429×264mm (21.93"×16.89"×10.39")

Upper/Lower Cover Depth: 45/169mm (1.77"/6.65")

Weight: 5.45kg (12.10lbs)

Material: PP

Pull Rod: 1

Wheels: 2

Handles: 3

Latch: 6

Temperature: -40°C~90°C (-40°F~194°F)

Waterproof: IP67

Packing: Carton

Standard:

1. Color: Black

2. Lining: Sponge (pre-cut blocks/egg pits)

3. Delivery Time: Samples in stock, <500 5~15 days, >500 10~25 days.

Customization:

1. Color: black, orange, yellow, gray, army green, camouflage.

2. Lining: Sponge (pre-cut blocks/egg pits), XPE, EVA, mesh bag, panel, etc.

3. LOGO/Nameplate: Silk screen, metal, epoxy, PVC, etc.

4. Delivery Time: Samples, 5~10 days, <500 5~15 days, >500 10~25 days.

5. Mold Opening: 20~30 days for small and medium-sized molds.

Features:

1. 100% new materials, patented formula

2. Stainless steel hardware accessories

3. Self-designed locking system

4. Smooth wheels

5. Automatic pressure release valve

6. One-time injection molding seal ring

7. Stackable

8. ROHS2.0 environmental protection test, IP67 waterproof test

9. Have a professional engineer team

10. Impact resistance, drop resistance, cold resistance, high temperature resistance, corrosion resistance

Application:

This wheeled PP protective case (493×368×221mm interior) is engineered for mobile professionals requiring heavy-duty protection combined with effortless transport. The integrated trolley system and compact footprint make it ideal for solo operators navigating airports, production sets, and rugged job sites. Key applications include:

1. Broadcast & Live Production: Securing portable vision mixers, audio console engines, RF monitoring systems, and field production switchers. The pull-handle enables rapid relocation between studio and outdoor shoots.

2. Medical Rapid Response: Housing automated external defibrillators (AEDs), transport ventilators, point-of-care ultrasound units, and trauma supply kits. Essential for ambulance bays and disaster relief deployments.

3. Industrial Inspection: Transporting phased array flaw detectors, high-end thermal imaging cameras, industrial borescopes, and calibration reference standards. Protects sensitive NDT equipment across refineries and construction sites.

4. Drone Operations: Carrying mid-sized mapping UAVs, ground control stations, multi-battery charging hubs, and payload sensors. The wheeled design eases transit between survey zones.

5. Tactical Communications: Organizing crypto-loaded radios, manpack transceivers, portable satellite terminals, and encrypted laptops for field operations.

6. Professional Audio: Storing digital mixing racks, power amplifiers, and wireless microphone receivers for touring engineers.

This case bridges the gap between airline-compatible carry-on and heavy-duty field protection, delivering unmatched mobility for high-value technical assets.
